Part Number:

9511419

CUMMINS Radiator - QSK-23-G3 ENGINE, 420KVA, 336KW, 50HZ, 1500RPM - 62 1/1" x 31 5/16" x 3 5/8"


Material:	Copper Brass

Manufacturer	CUMMINS
Model	QSK-23-G3 ENGINE, 420KVA, 336KW, 50HZ, 1500RPM
Year	-
Fuel	-
Transmission	-
Construction	Copper Brass
Core Height	62 1/1"
Core Width	31 5/16"
Core Depth	3 5/8"
Overall Size	62 1/1" x 31 5/16" x 3 5/8"
Core Style	VM (See Core Pattern)
No of Rows	6 Row
Inlet	3" Upper Left
Outlet	3-1/2" Lower Center
Fin Style	Louvered
Fin Type	Serpentine
Fins Per Inch	12 FPI
Tube Type	Seem Welded
Oil Cooler TOC	-
Oil Cooler EOC	-
Cross Reference/OEM	-
Note:	All OEM/Cross Reference numbers and dimensions are to be verified and are only there as points of reference.
