| Part Number: |
3511543 |
CATERPILLAR Radiator - C9C12 IND Engine C9C12 Engine - 33 3/8" x 23 1/8" x 4 1/2"
| Material: |
Copper Brass
|
|---|
Features
| Manufacturer | CATERPILLAR | |
| Model | C9C12 IND Engine C9C12 Engine | |
| Year | - | |
| Fuel | Diesel | |
| Transmission | Manual | |
| Construction | Copper Brass | |
| Core Height | 33 3/8" | |
| Core Width | 23 1/8" | |
| Core Depth | 4 1/2" | |
| Core Style | Mark-11 (See Core Pattern) |
|
| No of Rows | 6 Row | |
| Inlet | 2" Upper Right | |
| Outlet | 2" Lower Right | |
| Fin Style | Louvered | |
| Fin Type | Flat Fin | |
| Fins Per Inch | 8 FPI | |
| Tube Type | Seam Welded | |
| Oil Cooler TOC | - | |
| Oil Cooler EOC | - | |
| Cross Reference/OEM | 2305006, 6135146, 230-5006, 613-5146, 450645, 450645AT | |
| Note: | All OEM/Cross Reference numbers and dimensions are to be verified and are only there as points of reference. | |
