| Part Number: |
6811896 |
FREIGHTLINER RADIATOR - Cascadia (2014-2015) 35-3/4 x 39-9/16 x 2-1/8"
Aluminium Plastic Hour Glass tube Radiator without frame: 6801896
| Material |
Aluminium Plastic Hour Glass
|
|---|
Features
| Manufacturer | FREIGHTLINER | ||||||
| Model | Cascadia Evolution | ||||||
| Year | 2014-2015 | ||||||
| Fuel | Diesel | ||||||
| Transmission | Automatic | ||||||
| Construction | Auminium Plastic Hour Glass tube | ||||||
| Core Height | 35-3/4" | ||||||
| Core Width | 39-9/16" | ||||||
| Core Depth | 2-1/8" | ||||||
| Core Style | A9.8HG (See Core Pattern) |
||||||
| No of Rows | 1 Row | ||||||
| Inlet | 2-1/2" Upper Right | ||||||
| Outlet | 2-1/2" Lower Right | ||||||
| Oil Cooler TOC | 12" Centers (3/4"-16UNF) | ||||||
| Oil Cooler EOC | No | ||||||
| Fin Type | Serpentine | ||||||
| Fin Style | Louvered | ||||||
| Fins Per Inch | 14 FPI | ||||||
| Tube Type | Hourglass | ||||||
| Cross Reference/OEM | |||||||
| Note: | All OEM/Cross Reference numbers and dimensions are to be verified and are only there as points of reference. | ||||||
| Similar Parts | |||||||
